1.25A 30W 24V Wall Mount Power Adapter GS EN61347 Certificated

Product Categories
Dongguan Analog Power Electronic Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

1.25A 30W 24V Wall Mount Power Adapter GS EN61347 Certificated

  • 1
  • 2

Brand Name : Analog

Model Number : BZ024-240125-AG

Certification : EN61347 EN61558 EN60335 EN62368

Place of Origin : China

MOQ : Negotiable

Price : 2.5-3.5USD

Payment Terms : T/T

Supply Ability : 1,600,000~1,800,000PCS/Month

Delivery Time : 10-25 work days

Packaging Details : White box/Carton

Certificate : TUV/SUD EN61347 EN61558 EN60335 EN62368

Output : 30W 24VDC 1.25A

Logo : Customized

Test : Temperature test; Vibration test; Drop-Test;Over charging and discharging test

Color : White/Black

Warranty : 2 year (about 2.28 years for 24-hour-operation a day)

Contact Now

New design of 30W 1.25A 24V Wall Mounted Power AdapterGS Certificated EN61347approved

What is A power adapter used for?

Power adapter, also known as external power supply, is a power supply voltage conversion equipment for small portable electronic equipment and electronic appliances. It is commonly used in small electronic products such as mobile phones, LED field and laptops

Adantages
1. AC/DC Plug--Contains conductive metal shrapnel to improve the contact stability of the plug
2. End Buffer Design -- After rigorous bending experiments,the Power Adapter is strong and resistant for pulling
3. Bold pure copper wire --Transmission voltage loss is smaller and much more stable

Product Description

Output Voltage(VDC) Output Current (A) Output Power(W )
5.0~7.9 0.01~3.00 23.70
8.0~11.0 0.01~3.00 27.00
11.1~15.0 0.01~2.50 30.00
15.1~24.0 0.01~1.50 30.00
24.1~32.0 0.01~1.24 30.00

We can customize the plug according to your need, such as US / EU / UK / AU / KR /JP and other regions

Application: Air Purifier/Cleaner/Sweeper/Window Wiper

1.25A 30W 24V Wall Mount Power Adapter GS EN61347 Certificated


Specification Datasheet Table

Item Specification Datasheet Table Note
Description Product name single-output switch power adapter
Product type Wall mount/Desktop/Interchange
Model GQ24-240125-AG
Supply Ability 1,600,000~1,800,000PCS/month
Application as per customer requirments,etc
Mechanical Performance Color Black or White
Dimensions Subjected to final design
Output DC Connector 5.5x2.1x10mm optional
DC Cord / DC Jack L=1.2m / 1.5m or Customized
Plug type EU ,UK, US, AU, KC, PSE...
Electrical Performance Output Voltage & Frequency 24V
Output Current 1.25A
Output Power 30W
Ripple/Noise
300mVp-p Max.
Input Voltage & Frequency 90VAC~264VAC, 47~63HZ
Maximum AC Current Please refer to the specification datasheet for approval
Input Inrush Current 40A(RMS) Max, full load tested @AC230V 50HZ
Efficiency VI
Protection OVP,OCP,OTP,SCP & Input Protection
Environmental requirements Operating Temperature 0~40 ℃,
Storage Temperature -40~70 ℃
Operating Humidity 5%~90% Non-condensing
Storage Humidity 5%~90% Non-condensing
Reliability Warranty 2 year (about 2.28 years for 24-hour-operation a day)
MTBF ＞20,000 hour
Insulation Resistanc ＞ 30MΩ@500VDC; 60S
Hi-Pot Meet different safety standard
Leakage Current 0.25mA Max, full load tested @AC230V 50HZ
Compliance with EU directives law & regulations RoHS,REACH,PAHS
Safety Standard Certificate UL/ETL/FCC/CE/ GS/UKCA/ PSE/ KC/ SAA/ EAC/BIS/ICBR
Standards IEC61558/IEC60335/IEC61347/ETL1310/ IEC62368,GB4943, GB4706,etc...
EMC EN55014-1/EN55014-2 compliance
ESD (Air discharge@ 8KV, Contact discharge@ 6KV,(IEC61000-4-2)
Surge ±1KV @ common or different mode

Application

Application Field Products including but not limited to

Home/Household Appliances

(IEC61558)

 Robot Vacuum Cleaner, Floor Cleaning Robots,Window Cleaning Robots,Steam Mops,Electric Mops,Cold-air Cooler,Water Purifier,Air purifier,Dehumidifier, Humidifier,Aroma Diffuser,Mosquito Killer,Ice Maker
Led Lighting(IEC61347) Led Power Supply,Led Driver,Table/Desk Lamp,Led Strip Light,Led Desktop Fan,Grow Light,Led Plant Growth Lamp,OSRAM led,

IT Communications Equipment

(IEC62368=IEC60950+IEC60065)

 Router,Switch,Mobile phones,Tablet PC,Network, Radio and Television Equipment,PoE...
Audio Equipment(IEC62368) Speakers,Recording Machine,Microphone
Video Equipment(IEC62368) STB TV box,Computers
Security Device(IEC62368) Monitor,CCTV cameras,

Household and Similar

Electrical Appliances

(IEC60335)

 Electrical devices with lithium battery power supply requires battery charge adapter
Power Units( ETL1310) Electronic, electrical, mechanical or electron-mechanical products
Other Industries UAV,Drones,Balance Car,Unicycle,Segway,PS4 Game Players Home Healthcare ,Cash registers/Counting Machine,Counterfeit Detector
